4.95 Inch IPS TFT LCD Display Incell
High-performance 4.95-inch IPS TFT LCD display with incell technology, designed for POS/PDA applications requiring excellent visibility and durability.
| Application |
POS/PDA |
| Number of pixels |
540*960 pixels |
| Active Area |
61.64*109.58mm |
| Module Outline |
64.04*114.98*2.0mm |
| Aspect Ratio |
16:9 |
| Display Mode |
Normally Black |
| Viewing Angle (CR>10) |
85/85/85/85 (Typ) |
| Contrast Ratio |
1000MIN, 1500 (Typ) |
| NTSC |
70% (Typ) |
| LCM Brightness |
250cd/m² (Typ) 500cd/m² (Typ) |
| Interface |
MIPI |
| Operating Temperature |
-20~+70℃ |
| Storage Temperature |
-30~+80℃ |
TD4160 TFT LCD Display Module, 4.95-Inch IPS TFT LCD with MIPI Interface
4.95-Inch Capacitive Touchscreen TFT LCD Display Module Featuring MIPI Interface
The JT-4.95IPSINCELL is a 4.95-inch TFT-LCD display with a resolution of 540 × 960 pixels and a brightness of 250 cd/m². This module incorporates the TD4160-BOS-HHV30Z-0 controller IC and supports MIPI interfaces. Its overall dimensions are 64.04 mm (W) × 114.98 mm (H) × 2.0 mm (T), with an active area measuring 61.64 mm (W) × 109.58 mm (H). The analog supply voltage (Vdd) for the module ranges from 2.6V to 3.3V, with a typical value of 2.8V.
Featuring an IPS screen, this display module delivers clear visibility from a wide range of viewing angles. The JT-4.95IPSINCELL has an operating temperature range of -20°C to +70°C and a storage temperature range of -30°C to +80°C.
4.95 inch 540*960 TFT Touch Display Module Drawing
